Product details

GENERAL Invisibility of light source and minimalistic design of this suspended downlighter makes it atractive as an architectural element, whilst high optical and electrical efficency makes it usable lighting design tool.

OPTICS Lens made of PMMA, retracted from the bottom surface of the luminaire, emitting light through perforation on the surface. Retraction from the perforation enables invisibility of the light source, providing full visual comfort.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING Housing is made of extruded aluminium tube. Finish: epoxy polyester powder coating. Fine structured texture. Other colours available upon request.

EQUIPMENT Supplied with suspension kit.

ADDITIONAL Other light colour temperatures available upon request.

Technical data

ceiling mounted
finish:white finestructured paint
finish: gray finestructured paint
finish: black finestructured paint
CE marking
mounting on normally flammable surfaces
electrical safety
ingress protection
voltage
frequency
lamp type
* Please select the row to enable viewing and downloading of additional material.
Order code Description Ø/H[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
2761111XY PIKO /S 60dg /840 45 /500 0.70 240 60° IP20 <16 4.7 4000 >80 50000h L80B10 /SCDM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
** Replace XY with the color code when ordering ( e.g. 11 white, 21 grey, 31 black).
