Product details

GENERAL Highly efficient recessed luminaire for direct illumination.Intended for illumination of spaces in medical institutions, pharmaceutical and other high- tech industry, where technological processes require IP 55 protection degree. Full visual comfort is ensured with the latest optical and electrical components.

OPTICS Opal diffuser, with an extruded aluminium frame, provides a high sealed degree of the luminaire, while forming a flat surface simple for maintenance. Also available with optics DP.

LIGHTING MANAGEMENT The choice of the adequate control gear enables lighting management.

HOUSING Housing is made of steel sheet 0.6 mm thick. Final coating is white epoxy polyester powder of special reflective white colour.

APPLICATION The luminaire is intended for use in modular, as well as monolith and panel suspended ceilings, 1- 40 mm thick.

EQUIPMENT Supplied with mounting kit.

ADDITIONAL This luminaire can be optionally equipped with an EM module, enabling operation in the case of a power failure, both with the proper autonomy and with the central battery system (CBS). Other light colour temperatures available upon request.

Technical data

recessed ceiling
finish: white highly reflective paint
CE marking
mounting on normally flammable surfaces
electrical safety
ingress protection
lamp type
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] a/b/h[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
9045119XY ETNA DO 600 /840 HE 595/595/105 580/580/140 7.00 3426 IP55 <22 27.0 4000 >80 60000h L80B10 /SDCM 3
9045121XY ETNA DO 600 /840 HO 595/595/105 580/580/140 7.00 4845 IP55 <22 39.0 4000 >80 60000h L80B10 /SDCM 3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
