Product details

GENERAL Recessed, fixed luminaire for general illumination.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING Die cast aluminium housing, with epoxy polyester powder coating.

APPLICATION Applicable to all types of suspended ceilings that can be cut through.

EQUIPMENT Supplied with mounting kit.

ADDITIONAL Other light colour temperatures available upon request.

Technical data

recessed ceiling
finish:white finestructured paint
CE marking
mounting on normally flammable surfaces
earth
ingress protection
voltage
frequency
lamp type
* Please select the row to enable viewing and downloading of additional material.
Order code Description Ø/H[mm] Ø/h[mm] WEIGHT [kg] FLUX [lm]* IP Total Power [W] CCT [K] CRI Led Service Life
1574212XY CENT 350 32dg /840 86/80 76/100 0.10 350 32° IP20 4.3 4000 >80 15000h L70 / SCDM6
1574214XY CENT 900 50dg /840 86/120 76/140 0.15 900 50° IP20 8.0 4000 >80 150000h L80B20 /SCDM3
1574216XY CENT 1300 50dg /840 86/120 76/140 0.15 1300 50° IP20 12.0 4000 >80 150000h L80B20 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
** Replace XY with the color code when ordering ( e.g. 11 white, 21 grey, 31 black).
