CLEAN ROOM CLA

Product details

GENERAL Recessed luminaire for clean rooms with high energy efficiency. Fraunhofer IPA Institute certified to ISO classes 1-3, according to EN14644-1, hygienic design up to GMP (Good Manufacturing Practices) classes A-C.

OPTICS Multi-layered optics. The micro prismatic diffuser protects against glare. The insulating film ensures uniform light. The tempered protection glass provides a smooth surface for easy maintenance.

HOUSING Housing consists of two parts: the outer and inner casings. The outer casing is made of 0,8 mm thick steel sheet. The inner casing carries electronic components and is connected to the construction of the diffuser carrier. The surface is protected with antibacterial epoxy-polyester white powder, which is resistant to detergents. The construction ensures complete sealing with the ceiling. The connection of the two parts with the spring plate system is sealed. Easy mounting. Steel cables provide additional safety.

APPLICATION in monolith, panel and modular ceilings.

EQUIPMENT Supplied with mounting kit.

ADDITIONAL Zinc primer housing coating for corrosion prevention, Dynamic White and other light colour temperatures are available on request.

Technical data

recessed ceiling
Antimicrobial RAL9003 white powder coating smooth glossy
CE marking
mounting on normally flammable surfaces
electrical safety
impact protection
lamp type
voltage
frequency
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] a/b/h[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
9031101XY CLEAN ROOM CLA 600 /840 595/595/108 580/580/160 12.00 5550 IP65/IP65 <19 45.0 4000 >80 60000h L90B10/ SDCM 3
9031103XY CLEAN ROOM CLA 1200 /840 1195/295/108 1180/280/160 14.00 5400 IP65/IP65 <19 45.0 4000 >80 60000h L90B10 /SDCM 3
9031201XY CLEAN ROOM CLA 600 /940 595/595/108 580/580/160 12.00 5550 IP65/IP65 <19 48.0 4000 >90 60000h L90B10/ SDCM 3
9031203XY CLEAN ROOM CLA 1200 /940 1195/295/108 1180/280/160 14.00 5400 IP65/IP65 48.0 4000 >90 60000h L90B10/ SDCM 3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
