ETNA CR DO
GENERAL Highly efficient recessed luminaire for direct illumination. Fraunhofer IPA institute certified to ISO Class 1, according to EN14644-1, hygienic design up to GMP (Good Manufacturing Practices) class C.
OPTICS Opal diffuser made of polymethyl methacrylate (PMMA), specially formulated to meet requirements for optical quality, homogeneity and specific surface properties. Ideal for use in the food industry, due to the fact that it does not contain toxic substances.
The frame of extruded aluminium of special construction, provides a high sealed degree of the luminaire, while forming a flat surface simple for maintenance.
LIGHTING MANAGEMENT The choice of the adequate control gear enables lighting management.
HOUSING Housing is made of steel sheet. The final protection is an epoxy-polyester powder of a particular reflective white colour. The luminaire is sealed, while the construction and modality of mounting provide complete sealing with the ceiling.
APPLICATION The luminaire is intended for use in modular, as well as monolith and panel suspended ceilings.
EQUIPMENT Supplied with mounting kit.
ADDITIONAL This luminaire can be optionally equipped with an EM module, enabling operation in the case of a power failure, both with the proper autonomy and with the central battery system (CBS). Other light colour temperatures available upon request.
|Order code||Description||A/B/H[mm]||a/b/h[mm]||WEIGHT [kg]||FLUX [lm]*||IP||UGR||Total Power [W]||CCT [K]||CRI||Led Service Life|
|9046119XY||ETNA CR DO 600 /840 HE||595/595/105||580/580/140||7.00||3426||IP55/IP65||<22||27.0||4000||>80||60000h L80B10 /SDCM 3|
|9046121XY||ETNA CR DO 600 /840 HO||595/595/105||580/580/140||7.00||4845||IP55/IP65||<22||39.0||4000||>80||60000h L80B10 /SDCM 3|
|9046123XY||ETNA CR DO 1200 /840 HE||1195/295/105||1180/280/140||7.00||3771||IP55/IP65||<22||26.0||4000||>80||60000h L80B10 /SDCM 3|
|9046125XY||ETNA CR DO 1200 /840 HO||1195/295/105||1180/280/140||7.00||4756||IP55/IP65||<22||35.0||4000||>80||60000h L80B10 /SDCM 3|
