Product details

GENERAL  Tunnel lighting luminaire, part of BUCK smart tunnel illumination system. Appropriate for various tunnel types and other harsh environments. It’s longevity, energy efficiency and overall reliable performance ensure low usage costs.

OPTICS  A wide range of PMMA lenses assures optimal lighting solution for any tunnel situation. Required lighting intensities and uniformities are ensured while high energy efficiency is achieved.
Basically two types of light distributions are used for tunnel lighting:
SYM – symmetric light distribution is used for interior and entrance zone luminaires;
ASY – asymmetric light distribution is used for entrance and exit zone luminaires as counterbeam or probeam application.
Optics protector is made of 5 mm tempered glass.

HOUSING  Made of stainless steel 1.4571 / AISI 316 Ti (electrochemically polished and passivated for highest resistance to corrosion) and extruded aluminium alloy heatsink with conversion protection. The heatsinks are isolated from stainless steel housing, so there is no possibility of galvanic corrosion.

LIGHTING MANAGEMENT  Smart LED lighting solutions for tunnels and subways include fully integrated control systems to monitor and manage various factors such as levels of light outside and inside the tunnel, speed and density of traffic, various tunnel zones, motion, presence, speed detection… Buck provides various solutions for luminaires control souch as analog curent loop 4-20 mA interface (CLi), discrete time coded 230 V step dim interface (SDi), digital bidirectional RS-485 interface (RSi).

FEATURES  Luminaire system consists of lighting units with incorporated drivers for powering of LED light source. Performance and safety in different types of tunnels are achieved with a properly chosen optics from a wide range of light distributions. Easy mounting with fixed or adjustable brackets. Longevity assured by advanced protection against corrosion, impact and overheating.

Technical data

street lighting
CE marking
mounting on normally flammable surfaces
electrical safety
ingress protection
voltage
frequency
lamp type
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP Total Power [W] CCT [K] CRI Led Service Life
6424101XY VISION IN 1 SYM 509x296x60 8.00 5730 IP66 45.0 4000 >70 100000h L90B10 / SDCM3
6424102XY VISION IN 2 SYM 509x296x60 8.50 11460 IP66 90.0 4000 >70 100000h L90B10 / SDCM3
6424103XY VISION IN 3 SYM 509x296x60 9.00 17190 IP66 135.0 4000 >70 100000h L90B10 / SDCM3
6424203XY VISION IN 3 ASY 509x296x60 9.00 16576 IP66 135.0 4000 >70 100000h L90B10 / SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
** Replace XY with the color code when ordering ( e.g. 11 white, 21 grey, 31 black).
